Automated test classification

Classification on technical automated tests

Automated test strategy is one the **key factors** of technical tests.

The technical automated tests should be categorized in a way that the build management system can execute each category on dependent development phases.Continuous Integration focus mainly on development tests which are automated.
According to standards we can split tests in 3 main categories:

  • Unit testing : test component without external interactions (for example, no access to external system or databases)
  • Integration testing: test the components with interactions
  • System testing: test application as a whole

Each test categories contain many test types. Is it important to identify these categories in order to automate, execute them and finally use them as a core of Test Policy Development.

Automated tests in Continuous Integration

« Program testing can be a very effective way to show the presence of bugs, but it is hopelessly inadequate for showing their absence. »

— Edsger W. Dijkstra (Turing price 1972)

Bugs have a price

bugs-prices

The cost of bug fixing increase when discovered lately of the development phase.

Automated tests benefits

Cost

  • Developing relevant automated test decrease cost of bugs of 97%
  • Reduce cost of functional or acceptance tests which can focus on relevant test cases
  • Optimize maintenance cost and time
  • Optimize TCO (total cost of ownership)

Quality

  • Reduce technical debt
  • They reduce risks of delivery failure
  • Increase source code quality
  • Increase trust on development process
  • Ensure better roadmap follow-up
  • Time to market (identify and correct bug earlier)
  • Improve test capacity (other type of tests)

Automated tests in Continuous Integration

Why Do Automated Testing?

  • Avoid regressions
  • Allow systems/applications to continue to change without long « testing » phases
  • Finding defects and problems earlier and faster (local run and CI)
  • Ensure external integration points are working and continue to work as expected
  • Ensure the user can interact with the system as expected
  • Help debugging / writing / designing code
  • Help specify the behaviour of the system

Overall : increase project delivery speed and trust with built-in quality

Strategy and scope

Continuous Integration is targeting automated tests during the development phase.
Which means these tests:

  • Are held and managed by the developers

  • Can be executed locally (developer workspace) and in continuous integration

  • Are used by the developer to help him developing new application features

  • Improved trust in source code quality

Continuous Integration will not address tests other than development ones.
But other types of automated tests can be included in continuous integration.
Testing team should be involved into automated test to capitalize relevant scenario and enrich non-regression.

Tests scope

Continuous Integration actions focus on the development phase of the application

  • Inputs are mainly specifications/design
  • After, the delivery validation phase like acceptance tests are engaged

tests-scope

Tests in Continuous Integration

tests-in-ci

  • In development phase, tests are used mainly to ensure no regressions

  • Automated test process of Continuous Integration is separated in 3 main steps:

    • Unit testing
    • Integration testing
    • System testing
  • Each phase are automated and executed by continuous integration

  • The Automated Installation is a mandatory phase to execute System Tests

Tests classification

« Testing, is being uncertain. »

— Anonymous

Testing an application

tests-in-app

A given application can tested in various ways:

  • Unit tests check specific section of code (Mocks can be used to isolate components)
  • Integration tests check components interactions
  • System tests see the application as a whole

Automated test classification

Test automation can be separated into 3 categories
They have different characteristics:

  • Technical constraints
  • Environment scope
  • Execution speed requirements
  • Autonomy

Some tests used direct API of the source code, others use interface (UI, services…)

test-classification

Even if categories are strict in order to identify tests constraints, but:

  • Reusability of tests in different categories is possible (specially dealing with API)
  • Architecture can bring to adapt categories to technical needs (for example making performance tests on Services…)

Unit testing

Definition (from ISTQB and IEEE 610)The testing of individual software components or groups of related units.
FeaturesUnit testing refers to tests that verify the functionality of a specific section of code, usually at the function or class level. In an object-oriented environment, this is usually at the class level, and the minimal unit tests include the constructors and destructors. So it means that we have to shunt all the external interactions thanks to stubs or mocks.
ConstraintsIsolated from external component (database, system, other services…) to avoid non-deterministic behavior Can be run without any specific environment resources
ROIUnit tests improves QA and the ROI because its aims are: Eliminating construction errors before code is promoted to QA (efficient non regression test) Detecting easily in which component the problem is when there is a production issue Low maintenance issues, because tight to source code API
CostFast development (especially when written during development). Maintenance make easier by API reference (the IDE will show you differences, and the compilation validate methods signatures).
EnvironmentFast execution. Only needs unit test framework (like JUnit) and JVM. Execution limited to JVM (no external components like database).
TypesComponent tests are test cases and suite which use application API Mock tests are also Component tests which use Test doubles (mocks) to simulate internal or external components

Unit test definition

According to Roy Osherove:

  • A unit test is an automated piece of code that invokes a unit of work in the system and then checks a single assumption about the behavior of that unit of work.

  • A unit of work is a single logical functional use case in the system that can be invoked by some public interface (in most cases). A unit of work can span a single method, a whole class or multiple classes working together to achieve one single logical purpose that can be verified.

A good unit test is:

  • Able to be fully automated
  • Has full control over all the pieces running (Use mocks or stubs to achieve this isolation when needed)
  • Can be run in any order if part of many other tests
  • Runs in memory (no DB or File access, for example)
  • Consistently returns the same result (You always run the same test, so no random numbers, for example. save those for integration – or range tests)
  • Runs fast
  • Tests a single logical concept in the system
  • Readable
  • Maintainable
  • Trustworthy (when you see its result, you don’t need to debug the code just to be sure)

I consider any test that doesn’t live up to all these as an integration test and put it in its own « integration tests » project.

Unit test should focus on :

  • Readability (test one thing, meaningful message, naming convention…)
  • Maintainability (isolated, good mock management, state-based…)
  • Trust (separated from integration tests, use fixed values…)

Unit Test isolation

  • When communicating with the collaborators is awkward (such as a remote credit card verification system) the testing unit should be isolated by mocks when relevant
  • If you follow the principle of collaborator isolation you don’t want to use the real product or customer classes here, because a fault in the customer class would cause the order class’s tests to fail. Instead you use Mock / TestDoubles for the collaborators to avoid non-deterministic behavior.

Mocking the collaborators is not a mandatory and systematic pattern: it should be used when relevant:

  • Unit test autonomy
  • Complexity of environment
  • Remote services resulting into non-determinist test
  • Speed requirement

One typical use case is the « In Memory Database » which can be used by Unit Tests as a fake database. When switching in real database, the same tests can be used also as Integration Tests.

unit-test-isolation

Mock / Test double

Dummy objects are passed around but never actually used. Usually they are just used to fill parameter lists.

Fake objects actually have working implementations, but usually take some shortcut which makes them not suitable for production (an InMemoryTestDatabase is a good example).

Stubs provide canned answers to calls made during the test, usually not responding at all to anything outside what’s programmed in for the test.

Spies are stubs that also record some information based on how they were called. One form of this might be an email service that records how many messages it was sent.

Mocks are pre-programmed with expectations which form a specification of the calls they are expected to receive. They can throw an exception if they receive a call they don’t expect and are checked during verification to ensure they got all the calls they were expecting.

Integration testing

Definition (from ISTQB)Testing performed to expose defects in the interfaces and in the interactions between integrated components or systems.
FeaturesIntegration testing is any type of software testing that seeks to verify the interfaces between components against a software design. External interactions are effectives when relevant (no stub nor mocks).
ConstraintsExternal components available and fill with test data (database, system, other services…) Interconnection set-up between application and external components
ROIVery efficient non regression test. Give feedback on integration issues. Tight to application services. Can reuse unit tests code when relevant (unmocked). Integration tests improve the components’ integration : They allow interfaces’ issues to be located more quickly and fixed. Detecting easily between which component the problem is when there is a production issue
CostMaintenance make easier when using API reference. Can be more difficult when dealing with external components dependencies.
EnvironmentPotentially slow execution. Needs test framework (like JUnit), JVM and external component availability.
TypesService test: tests calling application services from external layer (ex.: Webservice calls) API test: tests calling application services directly by API calls

Note: When relevant, some unit test could be reused for integration test

Integration test definition

Definition:
Integration testing is testing a unit of work without having full control over all of it and using one or more of its real dependencies, such as time, network, database, threads, random number generators, and so on

Integration test:

  • can run slower
  • are separated to the unit tests
  • put them in their own « integration tests » or « test » project.
  • can also be written with Junit

System testing

Definition (from ISTQB)The process of testing an integrated system to verify that it meets specified requirements.
FeaturesSystem testing, or end-to-end testing, tests a completely integrated system to verify that it meets its requirements. All the external interactions might be effectives (no stub nor mocks). For example, a system test might involve testing a logon interface, then creating and editing an entry, plus sending or printing results, followed by summary processing or deletion (or archiving) of entries, then logoff.
ConstraintsExternal component available and fill with test data (database, system, other services…) Interconnection between application and external components set-up Application globally installed and available for client interaction Should be monitored in order to have feedback
ROISystem tests improve the requirements’ matching: They allow requirement matching issues to be detected more quickly and fixed Detecting easily which part of the system doesn’t allow to match the requirements Very efficient non regression test. Give feedback on global integration, performance and features behavior issues.
CostHeavy cost of set-up and maintenance: any changes on the application affecting the HMI, use cases or scenario expect tests updates.
EnvironmentSlow execution. Needs UI test and all application parts installed and available.
TypesSmoke test: preliminary testing to reveal simple fatal failures UI test: simulation of the HMI based on scenario Unit-performance test: load test behavior and measure performance

Note: When relevant, system test could be executed in an embedded container

System test ecosystem

System testing are all tests that consider the software as a whole

A lot of different test can be associated to system testing:

  • Graphical user interface testing
  • Usability testing
  • Software performance testing
  • Compatibility testing
  • Exception handling
  • Load testing
  • Volume testing
  • Stress testing
  • Security testing
  • Scalability testing
  • Sanity testing
  • Smoke testing
  • Exploratory testing
  • Ad hoc testing
  • Regression testing
  • Installation testing
  • Recovery testing and failover testing.
  • Accessibility testing

System testing expect to have an installed software : installation automation is mandatory when expecting System Testing automation.

Smoke test

The Smoke Test is the most basic System testing:
A subset of all defined/planned test cases that cover the main functionality of a component or system, to ascertaining that the most crucial functions of a program work, but not bothering with finer details.

A daily build and smoke test is among industry best practices. Smoke testing is also done by testers before accepting a build for further testing.

  • Microsoft claims that after code reviews, « smoke testing is the most cost-effective method for identifying and fixing defects in software ».

In the case of automated tools, the smoke tests are often initiated by the same process that generates the build itself.

Installation test

Installation testing

  • Quality assurance work that focuses on what customers will need to do to install and set up the new software successfully. The testing process may involve full, partial or upgrades install/uninstall processes.
  • Installation test execute installation of the application (with configuration, unit of delivery) on a target environment. The goal is to control the installation procedure and have an available application for other tests.

Constraints

  • Manage generic portable application configuration
  • Write scripts or use tools to automate installation of all the parts of the application in batch mode
  • Setup an orchestration mechanism through continuous integration to run through installation and analyse potential issues

Benefits

  • Integrate installation automation will bring a lot test capacities automation (performance, HMI, service…), reduce manual errors and installation time, ensure repeatability and provides industrialization capacity to the release process. And above all bring control on installation procedure.

Test development

The pupil asked the master programmer:
« When can I stop writing tests? »

The master answered:
« When you stop writing code. »

— The way of Testivus

Test development needs

Test development should be based on requirements and architecture needs:

  • Sensible components should have detailed tests
  • Tests should be developed depending of architecture : for example, JavaScript application will need more UI tests

Cost of test development and maintenance should not be underestimated (in particular when changing API and HMI)

  • Development of high-level tests like System Tests are sensible to application modification
  • Give advantage to API test (unit or integration) when refactoring (interesting for Agile development)

Tests can be reused on different categories changing configuration (in some cases, unit test can be reused in integration)

Test coverage should used carefully and when misunderstood could bring to useless tests development (ex.: testing getter-setter is often useless)

  • Test coverage should be used on sensible and complex component or class
  • A test coverage strategy should be set-up early (for example, during conception/architecture reviews/audit) to specify coverage expectations on sensible classes/methods

In Agile development, the automated tests (in particular unit test and integration tests) are developed very early

  • Methods like TDD (Test Driven Development), BDD (Behavior Driven Development) expect an essential role of the automated tests

Tests expectations examples

Unit testingIntegration testingSystem testing
Development goalTo verify component behavior. Mock should be used when relevant to avoid integration issues and non deterministic behavior.To verify services behavior and integration. Component should be un-mocked.To verify scenario validity, performance expectation, installation capacity.
Environment requirementMinimal container and dependencies, mandatory autonomy (ex.: no database dependency). Avoid non-deterministic behavior.External components available and accessible from applicationAvailable environment, test resources and dependencies. Application fully installed with external components, available by UI.
Example of tools and frameworksJUnit, H2 and HSQLDB (embedded database), MockitoJunit, JMeterSelenium, Jmeter, UFT
Executed by continuous integrationYESYESYES
Execution speedVery fast (less than 10 minutes)Slow (more than 10 minutes)Very Slow
Regularity of executionVery often (several times a day), associated to code updatesOften (1 per day)At night (1 per day)

Automated tests pyramid

tests-pyramid

Test pyramid well known in Agile development. Based on test development/maintenance cost and efficient regression detectionTest pyramid expects to have many more low-level unit tests than high level end-to-end testsHigh-level tests are there as a second line of test defenseShould be used when relevant

Test and build

Build verification test (from ISTQB):
A set of automated tests which validates the integrity of each new build and verifies its key/core functionality, stability and testability. It is an industry practice when a high frequency of build releases occurs (e.g., agile projects) and it is run on every new build before the build is released for further testing.

Automated tests should be executed by all ways possible : IDE, build tools, continuous integration…

Tests categories should be identified through the build tool :

  • For example, Maven should be able to select/avoid tests categories (execute only unit tests, or unit tests with integration tests…)
  • Build should be able to reused unit test source for integration test when relevant for integration testing (by managing mock profile for example)

Tests categories should have localisation pattern with the source code:

  • Unit tests should be near the code to test (for example, src/test/java according to Maven convention)
  • When relevant separate integration and system tests from tested components: put them in a ‘test’ component. The component could even be delivered.

Execution methods should be able to execute each categories of test separately or at the same time:

  • For example, Jenkins jobs should be able to execute only unit tests, or unit tests and integration tests…

See also

External links

Back to Blog
